HUNTER PGP Ultra

HUNTER PGP Ultra

HUNTER PGP Ultra

  • Ražotājs: Hunter | ASV
  • Kods:PGP Ultra 04
  • Pieejamība:Pieejams
  • 16.00€18.15€
  • Bez PVN:13.22€
Radius: 4.9 to 14.0 m
Flow: 0.07 to 3.23 m³/hr
Flow: 1.2 to 53.8 l/min
Inlet Size: ¾"


PGP Ultra / I-20 Blue Standard
Nozzle Performance Data
View Nozzle
Nozzle Pressure Radius Flow Precip mm/hr
  bar kPa m m³/hr l/min
1.5 •
Blue
 1.7 170 8.8 0.27 4.5 7 8
2.0 200 9.1 0.29 4.8 7 8
2.5 250 9.4 0.32 5.4 7 8
3.0 300 9.8 0.35 5.9 7 9
3.5 350 9.8 0.38 6.4 8 9
4.0 400 9.8 0.41 6.8 9 10
4.5 450 9.4 0.43 7.2 10 11
2.0 •
Blue
 1.7 170 10.1 0.32 5.4 6 7
2.0 200 10.1 0.35 5.8 7 8
2.5 250 10.1 0.39 6.5 8 9
3.0 300 10.4 0.43 7.2 8 9
3.5 350 10.4 0.47 7.8 9 10
4.0 400 10.4 0.50 8.3 9 11
4.5 450 10.4 0.53 8.8 10 11
2.5 •
Blue
 1.7 170 10.1 0.39 6.6 8 9
2.0 200 10.4 0.43 7.1 8 9
2.5 250 10.7 0.48 8.0 8 10
3.0 300 10.7 0.54 8.9 9 11
3.5 350 10.7 0.58 9.7 10 12
4.0 400 10.7 0.62 10.4 11 13
4.5 450 10.7 0.66 11.1 12 13
3.0 •
Blue
 1.7 170 10.7 0.50 8.4 9 10
2.0 200 10.7 0.54 9.1 10 11
2.5 250 11.0 0.61 10.2 10 12
3.0 300 11.6 0.68 11.4 10 12
3.5 350 11.9 0.74 12.3 10 12
4.0 400 11.9 0.79 13.2 11 13
4.5 450 11.9 0.84 14.0 12 14
4.0 •
Blue
 1.7 170 11.3 0.68 11.3 11 12
2.0 200 11.6 0.73 12.2 11 13
2.5 250 11.9 0.81 13.6 12 13
3.0 300 12.2 0.90 15.0 12 14
3.5 350 12.2 0.97 16.2 13 15
4.0 400 12.5 1.04 17.3 13 15
4.5 450 12.5 1.10 18.3 14 16
5.0 •
Blue
 1.7 170 11.3 0.84 14.0 13 15
2.0 200 11.6 0.91 15.2 14 16
2.5 250 11.9 1.02 17.1 15 17
3.0 300 12.8 1.14 19.0 14 16
3.5 350 12.8 1.24 20.6 15 17
4.0 400 12.8 1.32 22.1 16 19
4.5 450 12.8 1.41 23.4 17 20
6.0 •
Blue
 1.7 170 11.6 1.01 16.8 15 17
2.0 200 11.9 1.09 18.2 15 18
2.5 250 12.2 1.22 20.4 16 19
3.0 300 13.1 1.36 22.7 16 18
3.5 350 13.1 1.47 24.5 17 20
4.0 400 13.4 1.57 26.2 18 20
4.5 450 13.4 1.67 27.9 19 21
8.0 •
Blue
 1.7 170 11.3 1.35 22.5 21 25
2.0 200 11.9 1.46 24.3 21 24
2.5 250 12.5 1.63 27.2 21 24
3.0 300 13.4 1.81 30.2 20 23
3.5 350 13.7 1.95 32.6 21 24
4.0 400 14.0 2.09 34.8 21 25
4.5 450 14.0 2.22 36.9 23 26

Notes:
All precipitation rates calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.


PGP Ultra / I-20 Grey Low Angle
Nozzle Performance Data
View Nozzle
Nozzle Pressure Radius Flow Precip mm/hr
  bar kPa m m³/hr l/min
2.0
LA •
Grey
 1.7 170 7.3 0.33 5.6 12 14
2.0 200 7.6 0.36 6.0 12 14
2.5 250 7.9 0.40 6.7 13 15
3.0 300 8.2 0.45 7.4 13 15
3.5 350 8.5 0.48 8.0 13 15
4.0 400 8.8 0.52 8.6 13 15
4.5 450 9.1 0.55 9.1 13 15
2.5
LA •
Grey
 1.7 170 7.9 0.44 7.3 14 16
2.0 200 8.2 0.47 7.9 14 16
2.5 250 8.8 0.53 8.8 14 16
3.0 300 9.4 0.59 9.8 13 15
3.5 350 10.1 0.64 10.6 13 15
4.0 400 10.4 0.68 11.3 13 15
4.5 450 10.7 0.72 12.0 13 15
3.5
LA •
Grey
 1.7 170 8.5 0.58 9.7 16 18
2.0 200 8.8 0.62 10.3 16 18
2.5 250 9.1 0.68 11.4 16 19
3.0 300 10.1 0.75 12.5 15 17
3.5 350 10.7 0.80 13.3 14 16
4.0 400 11.0 0.85 14.1 14 16
4.5 450 11.3 0.89 14.8 14 16
4.5
LA •
Grey
 1.7 170 8.2 0.71 11.8 21 24
2.0 200 8.8 0.76 12.7 19 23
2.5 250 9.1 0.84 14.1 20 23
3.0 300 10.1 0.93 15.5 18 21
3.5 350 10.7 1.00 16.6 18 20
4.0 400 11.0 1.06 17.6 18 20
4.5 450 11.3 1.12 18.6 18 20

Notes:
All precipitation rates calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
